Roll Log Saw Cutting Machine for JRT or Maxi Roll

Description

1.Model: FS-JRT 2800 Industrial Roll Log Saw Cutter
2.This log saw machine match with maxi roll rewinder for production maxi roll, industrial paper roll, rolled hand towel.
3.Cutting Speed:40-80 rolls/min
4.PLC control,Servo Motor Driving, Touch Screen Operating Interface
5.Place of Origin: Foshan, China 6.Transport Package: Standard Exporot Wooden Cases

Chat Now Send Inquiry

Performance Description

Main Technical Parameter

Production Introduction

The full automatic Roll Log Saw Cutting Machine is a circular saw with rails, which can cut maxi roll toilet roll.The saw blade absorbs the foreign advanced Servo drive system from Germany, which greatly improves the stability and quality control of the paper towel machine.

1. The speed can be synchronized with any type of coiler.The saw is flexible to adjust the diameter of the cutting roller.Make the cutting clean without deformation

2. Roll Log Saw Cutting Machine for JRT or Maxi Roll is automatic feeding, smooth cutting surface and clean cutting

3. All are programmed on the servo drive.Reduce operator operating time and increase production time

4. Single feeding channel can reach 40-80 knives per minute.

5. The fixture system of logs can be customized.

6. Suitable for the production of high-grade MAxi roll, JRT, industrial roll, cloth cutting, is an ideal production line, PLC computer programming and servo drive system, cutting stability, speed can reach 80-100cut/m

7. Servo drive system to control and push saws in any size required range.

Technical Parameter

Model	1575-3500 Roll Log Saw Cutting Machine for JRT or Maxi Roll
Feeding Log Length	1800mm-3500mm
Log Diameter	225± 5mm (other size, please specify it)
Cutting Length	50~600mm (Cutting Length Adjustable)
Output Line	1 Lines
Speed	80 Cuts/Min, 1 Roll/Cut
Programmable controller	"Mitsubishi" Brand
Parameter setting	Touch Screen Operating Interface
Round Knife Outer Diameter	1000mm, Germany Brand
Function Mode	Spiral rotating the round blade & Continued Paper Roll Moving
Knife Grinding System	Pneumatic Grinding Wheel, Time Can Be Set Up By Touch Screen
Grinding Wheel	Carborundum grinding wheel
Driving System	Servo Motor Driving
Motor	Servo Motor
Power	380V, 50Hz, 18Kw
Weight	Approximate 6.5T
Dimension	Approximate 8.0M2.2M2.4M

Finished Products

Industrial Roll

Maxi Roll

Products Description

Q: Where are the wearing parts?

1. You can get the preferential price from our factory, but the freight is expensive, the transportation time is long, you can buy from the local

2. After the machine starts to run, you can prepare more wearing parts to avoid the trouble of replacement in the future.

Q: How do we maintain roll log saw cutting machine for JRT or Maxi roll if it breaks down?

1. Provide detailed operating instructions;

2. Overseas service, on-site service by technicians or engineers anytime and anywhere

3. Remind you to carry out machine maintenance such as oil routing, lubrication, inspection and parts replacement
